PROFESSIONAL
UltraBaseSystems is first and for most a STRUCTURALLY engineered subbase replacement system which successfully addresses the safety, drainage and aesthetic demands of an entire industry. From athletic fields to residential landscaping installations, putting greens to pet areas, concrete paver installations to athletic courts, UBS Professional Panels cover all of your base requirements.
The structural superiority of the panel is designed to dramatically reduce the need for extensive site preparation both indoors and outdoors, creating a base structure capable of supporting enormous loads while providing greatly improved GMAX and HIC impact numbers resulting in SAFER and more predictable playing surfaces.
Large water flow volumes both vertically and horizontally are achieved with UBS Professional creating a base system capable of rapidly directing rainwater away from the turf and the players.
MORE ABOUT PROFESSIONAL
Perfect planarity and the UBS patented non-slip turf barbs all help to create a base unlike anything the market has ever seen.
Simply Better From the Ground Up
Our Professional Panel was designed to minimize costly and time-consuming site preparation for both indoor and outdoor projects. We created a base structure that not only is capable of supporting enormously heavy loads, we also created a system that greatly improved both GMAX and HIC impact numbers. Simply put, we made better playing surfaces with a safer and more predictable base. Drainage is not a problem for UltraBaseSystems panels. They were designed to direct rainwater away from seeping above turf and affecting players by facilitating large water flow volumes both vertically and horizontally. Our patented interlocking tooth design allows perfect and smooth alignment from panel to panel, while our non-slip turf barbs mean your turf isn’t going anywhere. There is nothing else like these panels out there.
Engineered to Perform
Safe and Strong, “Built solid to play safe” isn’t just a catch phrase, it’s our mission! We’ve created a high-performance panel system that is structurally superior to its competitors. We proudly manufacture all of our panels from high impact, post-industrial recycled polymers, and then mold them into a patented geometric design that can not only withstand heavy loads and high impact, but can also provide a superior drainage system for any installation. The technology behind our panel system allows for reduced ground preparation, minimizing install times and cost of labor.
Drain Slots
Our vertical flow rates of the Pro panel can range from 340 inches to 1500 inches per hour, and horizontal flow rates are at about 126 inches per hour. Each UBS panel can store 3.58 gallons underneath it! This is all due to our patented under side cell design that allows water to store then rapidly flow without clogging through super-sized multi-directional drain slots on the underside of the panel.
Cell Structure
Because we designed our base panel system as a replacement for compacted rock, asphalt, or concrete, that mean that we had to make something that would be able to withstand the same load capacity. Well, we did. Due to engineering our panels with a 4.25’’ hexagonal cell structure, we’ve created a static load capacity for the weakest location of the panel equivalent to 374 psi (26.3 kgf/cm2). Load values when placed over a full descending cellular rib are 998 psi (70.17 kgf/cm2). Our panels can take loads like forklifts, emergency vehicles and utility trucks, among others.
Turf Grip
Our panels contain 3,000 turf barbs each. These patented barbs create highly coefficient friction which removes the turf movement issues you may face with other base systems like stone.
When paired with a felt or foam backed turf, our barbs will create a stationary turf system that won’t move while it is properly installed on UltraBaseSystems panels. That means we’ve created a system that requires less infill for your turf.
Our Professional Panel was designed to minimize costly and time-consuming site preparation for both indoor and outdoor projects.
We created a base structure that not only is capable of supporting enormously heavy loads, we also created a system that greatly improved both GMAX and HIC impact numbers. Simply put, we made better playing surfaces with a safer and more predictable base. Drainage is not a problem for UltraBaseSystems panels. They were designed to direct rainwater away from seeping above turf and affecting players by facilitating large water flow volumes both vertically and horizontally. Our patented interlocking tooth design allows perfect and smooth alignment from panel to panel, while our non-slip turf barbs mean your turf isn’t going anywhere. There is nothing else like these panels out there.
